Produktbeskrivning

The HPE 16GB Host Bus Adapters bring datacenter infrastructure components to a higher level of performance and efficiency with the ability to deliver twice the I/O performance of 8Gb HBAs at lower latency. A 16Gb FC HBA purchased today is backward compatible with 8 Gb and 4 Gb storage networks and will protect future investments. When using storage intensive applications, such as backup/restore, database transactions, virtualization, and rich media, the increased performance of the 16 Gb infrastructure enables more rapid storage and retrieval of critical information. Designed for environments with greater virtual machine density and bandwidth requirements, the 16Gb HBAs enable more applications and VMs to run on a single host server and Fiber Channel port, resulting in reduced cabling and a higher return on IT investment. The four port adapters are specially designed for PCIe slot constrained servers which run workloads that demand extremely high storage networking bandwidth.



Egenskaper

● Delivers, up to six times the IOPS, twice the data throughput (MB/s) and cuts latency by half compared to 8 Gb FC HBAs
● Ideal for high density server virtualization environments



Teknisk specifikation

Typ av enhet	Värdbussadapter
Formfaktor	Instickskort - låg profil
Gränssnittstyp (buss)	Fibre Channel

Portar	16Gb Fibre Channel x 1
Anslutningsteknik	Kabelansluten
Typ av kablage	Fiberoptisk
Datalänkprotokoll	16Gb Fibre Channel

Gränssnitt	1 x 16Gb Fibre Channel

Operativsystem erfordras	SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008 R2 x64 Edition, Microsoft Windows Server 2008 (32/64-bits), VMware ESXi, VMware ESX

Designat för

HPE Apollo 4200 Gen10, 4510 Gen10 HPE Nimble Storage dHCI Medium Solution with HPE ProLiant DL360 Gen10, Small Solution with HPE ProLiant DL360 Gen10 HPE ProLiant DL325 Gen10 Plus V2 Base, DL325 Gen10 Plus V2 Performance, DL345 Gen10 Plus, DL345 Gen10 Plus Base, DL345 Gen10 Plus Entry, DL360 Gen10, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Base, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL365 Gen10 Plus, DL385 Gen10 Plus, DL385 Gen10 Plus Entry, DX360 Gen10 Plus, XL170r Gen10 Server for BlueData EPIC, XL190r Gen10, XL190r Gen10 for HPE Ezmeral Container Platform, XL220n Gen10 Plus, XL270d Gen10, XL270d Gen10 for HPE Ezmeral Container Platform, XL290n Gen10 Plus, XL645d Gen10 Plus
