Egenskaper

Seamless large screens with ultra- narrow bezel
The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.

Image gap reduction
The VL5G-M series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

Higher viewing angle
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5G-M series is high enough to display vivid colors throughout the screen with no distortion.

Wide viewing angle
It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5G-M series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.

Easy color adjustment
Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

White balance adjustment
In conventional video walls, white balance was adjustable only in "full-white" mode, but the VL5G-M series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.

User-friendly menu structure
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.

Intuitive GUI
The GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a large font for better visibility, which is necessary when users want to control displays from relatively far distances.



Teknisk specifikation

Typ av produkt	LED-bakgrundsbelyst, platt LCD-skärm
Strömförbrukning (max)	120 Watt
Energiförbrukning vid drift	100 Watt
Diagonalklass	49"
Kommersiell användning	Ja - digital skyltning
Serie	VL5G-M Series
TV-tuner	Ingen mottagare
TV-mottagaravkänning	Nej
Videogränssnitt	HDMI
HDMI-portskvantitet	2 portar
PC-gränssnitt	DVI, DisplayPort
Lägen	Stående läge, liggande läge
Bildförbättringar	Image Gap Reduction, Bred synvinkel
Design	Ultrasmal kant
Dimensioner	Utan ställ
Bredd	107.76 cm
Djup	8.97 cm
Höjd	60.78 cm
Vikt	16.9 kg
Färg	Svart

LCD-skärmteknik	IPS
Upplösning	1920 x 1080
Visningsformat	1080p
Bildkvot	16:9
LCD-teknik för bakgrundsbelysning	LED-bakgrundsbelysning
Bildkontrastförhållande	1000:1
Ljusstyrka	500 cd/m²
Bildvinkel	178 grader
Bildvinkel (vertikal)	178 grader
Svarstid	8 ms
Kommersiella funktioner	LG SuperSign Media Editor, kompatibel med SuperSign CMS, SuperSign Control+ kompatibel, SuperSign Control compatible, kompatibel med SuperSign WB
Driftstimmar / dagar	24 / 7
Egenskaper	Justerbar vitbalans

Monteringsgränssnitt för platt bildskärm	600 x 400 mm
Överensstämmer med VESA	Ja

USB-port	Ja
Antal USB-portar	1

Typ	Fjärrkontroll
Batteri ingår	Ja
Antal batterier som medföljer	2

Anknytningsbarhet	LAN

Anslutningstyp	2 x HDMI-ingång DisplayPort-inmatning DVI-D-ingång Linjeingång för ljud USB 2.0 DisplayPort-utmatning Linjeutgång för ljud RS-232C in-/utgång Fjärrkontroll Infrared (IrDA)

Inkluderade tillbehör	IR-mottagare, guidefäste
Medföljande kablar	RS-232C-kabel DisplayPort-kabel
Standarder som följs	FCC klass A-certifierad, CB, EMC, KC, ERP, NRTL

ENERGY STAR-certifierad	Ja

Nätdel	Nätaggregat
Inspänning	AC 100-240 V (50/60 Hz)

Bredd (brutto)	121.4 cm
Djup (brutto)	26.3 cm
Höjd (brutto)	77.8 cm
Vikt (brutto)	29.3 kg

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	10 - 80%
