Produktbeskrivning
This GBIC is built to insert into any one of the two built-in 10 GE SFP+ interfaces of GSM7328Sv2 and GSM7352Sv2, and into the 10GE SFP+ interface of AX743 adapter module for GSM73xxS/GSM73xxSv2. Once inserted (hot-swappable), the AXM761 10GBASE-LR SFP+ (LC connector) drives 10 Gigabit Ethernet up to 10 km distances with 9/125µm SMF single mode fiber cables, or up to 33 m distances with 62.5/125µm OM1 multimode fiber cables.
This is a pack of 10 AXM762 SFP+ modules.
Egenskaper
● Adds 10Gigabit Ethernet "long-reach" LC fiber connectivity to the standard SFP+ interfaces
● Fits into the two built-in 10GE SFP+ interfaces of GSM72xxPS / GSM73xxS
● Fits into the 10GE SFP+ interface of the SFP+ Adapter module AX743
● Fits into standard 10 Gigabit SFP+ interfaces
● LC connector
● Drives 10 Gigabit Ethernet up to 10 km distances with 9/125 µm SMF single mode fiber cables
● Drives 10 Gigabit Ethernet up to 300 m distances with 50/125 µm laser-optimized OM3 multimode fiber cables
● Drives 10 Gigabit Ethernet up to 33m distances with 62.5/125 µm OM1 multimode fiber cables
● Provides hot-swappable installation or removal
● 10GBaseLR fiber technology is the same for XFP and SFP+: one Switch equipped with XFP 10GBase-LR LC connectivity can uplink to another Switch equipped with SFP+ 10GBase-LR LC connectivity using the same fiber
Teknisk specifikation
Allmänt
| Förpackad kvantitet | 10 (specificationerna gällerenskild post) |
|---|
| Typ av enhet | SFP+ sändar/mottagarmodul |
|---|
| Formfaktor | Insticksmodul |
|---|
Nätverksfunktioner
| Anslutningsteknik | Kabelansluten |
|---|
| Typ av kablage | 10GBase-LR |
|---|
| Datalänkprotokoll | 10GbE |
|---|
| Dataöverföringshastighet | 10 Gbps |
|---|
| Optisk våglängd | 1310 nm |
|---|
| Max överföringsavstånd | 300 m |
|---|
| Standarder som följs | IEEE 802.3ae |
|---|
Expansion/Anslutning
| Gränssnitt | 1 x Ethernet 10GBase-LR - LC-enkelläge x 2 |
|---|
| Kompatibla kortplatser | 1 x SFP+ |
|---|
Diverse
| MTBF (genomsnittstid mellan fel) | 4,986,536 timmar |
|---|
| Standarder som följs | UL 1950, CSA 22.2 No. 950, RoHS |
|---|
Mått och vikt
| Bredd | 1.37 cm |
|---|
| Djup | 5.57 cm |
|---|
| Höjd | 1.19 cm |
|---|
| Vikt | 19.2 g |
|---|
Tillverkarens garanti
| Service och support | Begränsad garanti - 5 år |
|---|
Miljöparametrar
| Min temperatur vid drift | 0 °C |
|---|
| Max temperatur vid drift | 70 °C |
|---|
