Produktbeskrivning
WD Blue drives are designed and manufactured with the proven technology found in WD's original award-winning desktop and mobile hard drives. Built to the highest standards of quality and reliability, these drives offer the features and capacity ideal for your everyday computing needs. These drives are available in a broad range of capacities, cache sizes, form factors and interfaces so you can be sure there's a drive that's the perfect fit for your system, in more ways than one.
Egenskaper
The original
WD Blue drives are designed and manufactured with the proven technology found in WD's original award-winning desktop and mobile hard drives.
WD quality
Built to the highest standards of quality and reliability, these drives offer the features and capacity ideal for your everyday computing needs.
More options
These drives are available in a broad range of capacities, cache sizes, form factors and interfaces so you can be sure there's a drive that's the perfect fit for your system, in more ways than one.
NoTouch Ramp Load technology
The recording head never touches the disk media ensuring significantly less wear to the recording head and media as well as better drive protection in transit. SATA or PATA interface. While SATA has become the industry standard interface, WD continues to manufacture desktop drives with a PATA interface for unique or legacy systems.
Tested for compatibility
WD perform tests on hundreds of systems and a multitude of platforms in the FIT Lab to give the customers confidence that the drives will work in their systems
Upgrading your drive is easy.
The WD advantage
WD puts the products through extensive Functional Integrity Testing prior to any product launch. This testing ensures the products consistently meet the highest quality and reliability standards of the WD brand.
Teknisk specifikation
Allmänt
| Typ av enhet | Hårddisk - inbyggd |
|---|
| Kapacitet | 8 TB |
|---|
| Formfaktor | 3.5" |
|---|
| Gränssnitt | SATA 6Gb/s |
|---|
| Buffertstorlek | 256 MB |
|---|
| Egenskaper | NoTouch-rampladdningsteknik, Advanced Format-teknik, CMR (Conventional Magnetic Recording), Low Power Management |
|---|
| Bredd | 101.6 mm |
|---|
| Djup | 147 mm |
|---|
| Höjd | 26.1 mm |
|---|
| Vikt | 715 g |
|---|
Prestanda
| Hårddiskens överföringshastighet | 600 MBps (extern) |
|---|
| Intern datafrekvens | 215 MBps |
|---|
| Spindelhastighet | 5640 rpm |
|---|
Pålitlighet
| Oåterkalleligt fel | 1 per 10^14 |
|---|
| Ladda/ladda ur cykler | 300,000 |
|---|
Expansion och anslutningar
| Gränssnitt | 1 x SATA 6 Gb/s |
|---|
| Kompatibelt fack | 3.5" |
|---|
Strömtillförsel
| Strömkonsumtion | 5.2 Watt (läsning/skrivning)
3.4 Watt (inaktiv)
0.4 Watt (viloläge)
0.4 Watt (viloläge) |
|---|
Programvara & Systemkrav
| Medföljande programvara | Acronis True Image WD Edition |
|---|
Diverse
| Standarder som följs | UL, TUV, VCCI, BSMI, ICES-003, FCC, Directive 2011/65/EU, RCM, Directive 2015/863/EU, UKCA, Maghreb |
|---|
Tillverkarens garanti
| Service och support | Begränsad garanti - 2 år |
|---|
Miljöparametrar
| Min temperatur vid drift | 0 °C |
|---|
| Max temperatur vid drift | 60 °C |
|---|
| Min temperatur vid förvaring | -40 °C |
|---|
| Max temperatur vid förvaring | 70 °C |
|---|
| Stöttolerans (vid drift) | 70 g @ 2 ms |
|---|
| Stöttolerans (i vila) | 250 g @ 2 ms |
|---|
| Ljudnivå | 24 dBA |
|---|
