Egenskaper

Modular building block for open, composable disaggregated IT infrastructure
With the exponential growth in data, along with the increasing diversity of workflows and demands on IT infrastructure, businesses need to increase speed, agility, and time-to-value for their customers. Emerging as a solution for this, composable disaggregated infrastructure is a modern architectural approach that - using NVMe-over-Fabrics - will vastly improve compute and storage utilization, performance, and agility in the data center. OpenFlex is based on scale-out performance and open composability.

Enabling fast data to live outside the server
NVMe-over-Fabrics, or NVMe-oF, is a networked storage protocol that allows storage to be disaggregated from computer to make that storage widely available to multiple applications and servers. By enabling applications to share a common pool of storage capacity, data can be easily shared between applications, or needed capacity can be allocated to an application to respond to application needs. Exploiting NVMe device-level performance, NVMe-oF promises to deliver low end-to-end latency from application to shared storage. NVMe-oF enables composable infrastructures to deliver the data locality benefits of NVMe direct attached storage (low latency, high performance) while providing the agility and flexibility of sharing storage and compute. OpenFlex's scale-out performance is particularly useful for large analytics tasks, large-scale high-performance computing and other demanding workloads.

Multiple storage tiers over the same wire - disk and flash accessed via NVMe-oF
In addition to enabling NAND flash media access using NVMe-oF, OpenFlex also enables disk and other IT components such as GPUs, FPGAs and even tape to be accessed via NVMe-oF so that all data center storage can be addressed in the same way. The Western Digital NVMe-oF architecture is a huge step towards the software-defined data center - allowing storage to be assigned to applications without regard for where it is physically located. This is the essence of "composable infrastructure" where physical resources (compute, networking, storage) can be logically and dynamically configured and treated as a resource for a specific application without the need for physical configuration.



Teknisk specifikation

Typ av enhet	Kabinett för lagringsenheter

Total array-kapacitet	61.44 TB

CPU	Ingen CPU

Typ	SSD
Typ av gränssnitt	PCI Express
Antal skrivningar per dag (DWPD)	0.8
Egenskaper	Instant Secure Erase (ISE), Read-Intensive Endurance

Gränssnitt	2 x Ethernet 50Gb - QSFP28 1 x hantering - RJ-45

Egenskaper	Non-Volatile Memory Express over Fabric (NVMe-oF)

Bredd	3.753 cm
Djup	69.44 cm
Höjd	12.411 cm
Vikt	4.44 kg

Min temperatur vid drift	5 °C
Max temperatur vid drift	35 °C
Luftfuktighet vid drift	8 - 85 % (icke-kondenserande)
